RF I/O SW917-4E-BU-2,2Ah LBT

Applied standards

EN IEC 60947-5-1, EN 301 489-3, EN IEC 61000-6-2, EN IEC 61000-6-3, EN IEC 63000

Enclosure

ABS, UL 94 HB, RAL 9005

Tightening torque

enclosure mounting screws: max. 1.5 Nm
cover screws: max. 1.5 Nm

Degree of protection

IP65 (IEC/EN 60529), only with plugged cables and/or with closed protective caps

Ambient temperature

–20 °C … +80 °C

Type of installation

mount on an even surface

Mounting position

any

Mounting

screw connection

Connection

4 x socket M8 x 1, 4-pole

Switching thresholds

max. switch-on threshold: 2.05 V,
min. switch-off threshold: 0.95 V

Switch-on delay t_on

max. 0.94 ms

Switch-off delay t_off

max. 94.7 ms

Actuating time

min. 80 ms

Telegram rate

max. 12000 telegrams with repetitions/h

Switching frequency

max. 5 Hz

Standby current

60 µA

Note

status signal – can be individually configured via radio receiver (delivery state: without status signal)
LBT – can be deactivated via radio receiver (e.g. in conjunction with repeaters)
transmission of battery voltage and switching condition

Wireless approvals

Brazil: ANATEL 04172-18-06718

Protocol

sWave®

Frequency

917 MHz (Brazil)

Transmission power

< 25 mW

Data rate

66 kbps

Channel bandwidth

550 kHz

Wireless range

max. 450 m outdoors, max. 40 m indoors

Modulation type

2-FSK

Voltage source

lithium battery Tadiran TL-5903 (replaceable)

System

Li/SOCl₂

Nominal voltage

3.6 V

Nominal capacity

2.4 Ah

Battery life

depending on the switching frequency and number and type of sensors for 1000 transfers/day and one inductive sensor approx. 300 days; for 1000 transfers/day and one mechanical switch approx. 1400 days
