RF 97 BU SW868

Applied standards

EN IEC 60947-5-1, EN 300 220-2, EN 301 489-3, EN IEC 61000-6-2, EN IEC 62368-1, EN IEC 63000

Enclosure

thermoplastic, glass-fibre reinforced, shockproof, self-extinguishing UL 94 V-0, weathering resistant, UV stabilised

Degree of protection

IP67 (IEC/EN 60529)

Safety class

III

Ambient temperature

–25 °C … +70 °C

Operation cycles

max. 1800/h

Connection

socket M8 x 1, 4-pole

Connectable devices

RF IS M* FL, RF RC M*, external switches using a connecting cable with open wire ends

Switching frequency

max. 5 Hz

Note

transmission of battery voltage and switching condition

General

Frequency

868.3 MHz (Europe)

Data rate

66 kbps

Channel bandwidth

400 kHz

Modulation type

2-FSK

Protocol

sWave®

Transmission power

< 25 mW

Wireless approvals

Europe: RED 2014/53/EU

Function

Telegram rate

max. 12000 telegrams with repetitions/h

Wireless range

max. 450 m outdoors, max. 40 m indoors

Collision avoidance procedure

LBT - Listen before Talk software

Note

status signal – can be individually configured via radio receiver (delivery state: without status signal)
LBT – can be deactivated via radio receiver (e.g. in conjunction with repeaters)
Go to our different wireless receivers to find corresponding how-to videos.

Voltage source

lithium battery (replaceable)

System

Li/SOCl₂

Nominal voltage

3.6 V

Nominal capacity

1.2 Ah

Standby current

3 µA (without external device)

Battery life

Inductive sensor RF IS ... FL: approx. 4 years
External contact / Magnetic sensor: >10 years
