Actuating radius narrow edge The axis of the hinge should be x mm above the top edge
of the safety switch and in the same plane.
a = Actuating radius to the plane of the actuator
x = Axial misalignment

Attention! x must be referred to the surface of the enclosure and not to the inserted actuator!

Accessories for ST 14 / Ex ST 14

Flexible actuator ST 14-B3

Article no.: 1040842 Old article no.: 04.14.8203

contact us

Product features

  • Especially suitable for hinged guards

  • Stainless steel 1.4301

  • Actuating radius on hinged guards:
    Axial misalignment x = 14 mm; a = min. 90 mm
    Axial misalignment x = 0 mm; a = min. 50 mm

Notes

  • 1 slot sealing plug is included in delivery

Downloads

Data sheet – Flexible actuator ST 14-B3

English

PDF 100 KB 16.11.2023
Data sheet – Flexible actuator ST 14-B3

Chinese

PDF 123 KB 16.11.2023
