Wireless hand control
RF HB
Thermoplastic enclosure
sWave® wireless technology (SW868/SW915/SW917/SW922)
Keypad with four function keys
Surrounding sealing (shock protection)
With lanyard keychain mounting
Power supply by Lithium battery
Easy programming of receiver
Output signal can be individually configured at the receiver
Available with "LBT - Listen before Talk" software (necessary in conjunction with potential interference)
Technical data
General technical data
Applied standards
EN 60947-5-1, EN 61000-6-2, EN 61000-6-3, EN 61000-4-2, EN 301 489-1, EN 301 489-3, EN 300 220-1, EN 300 220-2
Enclosure
ABS, graphite grey, similar to RAL 7024
Decor seal
TPE, signal red, similar to RAL 3001
Degree of protection
IP54 (IEC/EN 60529)
Ambient temperature
–20 °C … +65 °C
Storage and shipping temperature
–40 °C … +85 °C
Telegram rate
max. 12000 telegrams with repetitions/h; SW922: max. 1440 telegrams/h
Wireless range
SW868/915/917:
max. 450 m outdoors,
max. 40 m indoors
SW922:
max. 150 m outdoors,
max. 20 m indoors
Mechanical life
> 1 million operations
Actuating time
min. 80 ms
Note
transmission of battery voltage and switching condition
Wireless approvals
Europe: RED 2014/53/EU
USA: FCC - XK5-RFRXSW915
Canada: IC - 5158A-RFRXSW915
Mexico: IFT - RCPSTRF17-1886
Brazil: ANATEL 04172-18-06718
Japan: ? ARIB STD-T108: 204-610002
Voltage supply
Voltage source
lithium battery CR 2032 (replaceable)
System
Lithium-MnO2
Nominal voltage
3 V
Nominal capacity
0.23 Ah
Battery life
> 800 000 operations
Downloads
Variants / Options
The following variants / options are available on request:
LBT - Listen before Talk software (necessary in conjunction with potential interference)
