Product features
Thermoplastic enclosure
Spring-to-lock principle
Locking force 1000 N
Wiring compartment
With LED
FE: with auxiliary release by male triangular wrench M5
Notes
The actuator is not included in the delivery of the switches.
Technical data
General technical data
- Applied standards
- EN ISO 13849-1, EN 60947-5-1, EN ISO 14119
- Enclosure
- thermoplastic, glass-fibre reinforced, shockproof, self-extinguishing UL 94 V-0
- Switch type
- type 2
- Coding level
- low coding
- Tightening torque
- cover screws: 0.5 … 0.6 Nm
enclosure mounting screws: 1 … 1.3 Nm
switch inserts M3 screw connection terminals: min. 0.6 Nm
solenoid M3.5 screw connection terminals: min. 0.8 Nm
- Degree of protection
- IP67 (IEC/EN 60529)
- B10d (10 % load)
- 1 million
- TM
- max. 20 years
- Switching system
- slow action, positive break NC contacts A
- Switching elements
- 1 NC/1 NO contact + 2 NC, type Zb
- Connection
- screw connection terminals
- Cable cross-section
- min. 0.2 mm² (AWG 24), max. 1.5 mm² (AWG 16)
- Cable entry
- 2 x M20 x 1.5
- Rated insulation voltage Ui
- 250 V
- Rated impulse withstand voltage Uimp
- 4 kV
- Conventional thermal current Ithe
- 4 A
- Utilisation category
- AC-15; DC-13
- Rated operating current/voltage Ie/Ue
- enabling/signalling contacts: 4 A/250 VAC; 0.25 A/230 VDC;
direct-current solenoid: 0.08 A / 24 VDC +10 %/–15 %
- Short-circuit protection
- 6 A gG fuse;
direct-current solenoid: 2 A (slow blow)
- Safety class
- II
- Power consumption
- <2.5 W (continuous operation), max. 47 W (for 250 ms)
- Operation cycles
- max. 1200/h
- Mechanical life
- > 500 000 operations
- Locking force Fmax
- 1000 N
- Ambient temperature
- –20 °C … +55 °C
- Weight
- 420 g
Dimensional drawing
Further drawings
Contact diagram
A positive break
P actuated
Q not actuated
Æ monitoring of the guard-lock to EN ISO 14119
