RF RxT SW2.4LE-IND - SET

Applied standards

EN 300 328, EN 301 489-17, EN IEC 62368-1, EN 60947-5-1, EN IEC 63000

Enclosure

polyamide, self-extinguishing UL 94 V-0, RAL 7035

Tightening torque

screw connection terminals: 0.5 … 0.6 Nm

Degree of protection

IP20 (IEC/EN 60529)

Mounting

DIN rail mounting

Connection

screw connection terminals 0.14 mm² - 2.5 mm² / AWG 26 … 14, stripping length 8 mm / 0.3 in

Rated operating current/voltage I_e/U_e

< 60 mA/24 VDC ±15 %;
output contacts: 5 A / 250 VAC, 30 VDC (resistive load)

Outputs

5 NO contacts (relay)

LED display

LED Power:
green: power supply is switched on
red: internal error
LEDs K1…4 + VAL:
off: relay not energised
orange: relay energised

Degree of pollution

2

Rated insulation voltage U_i

250 VAC

Rated impulse withstand voltage U_imp

2.5 kV

Ambient temperature

0 °C … +55 °C

Storage and shipping temperature

–25 °C … +85 °C

Teachable transmitters

1

Telegram rate

20 ms (bidirectional)

Synchronisation after sleep mode

67 ms (typical), 110 ms (max)

Mechanical life

K1…4: > 5x10⁶ operations
VAL: > 10x10⁶ operations

Electrical life

K1…4: > 1x10⁵ operations AC1
VAL: > 1x10⁵ operations AC1

Shock resistance

K1…4: 1 g
VAL: 7 g

Vibration resistance

K1…4: 2 g (10-55 Hz)
VAL: 2 g (10-200 Hz)

Risk time

120 ms: After the risk period has elapsed, the receiver switches to the safe state (all relays de-energised)

Wireless approvals

Europe: RED 2014/53/EU
USA: FCC-Id. XK5-SW24LE
Canada: IC - 5158A-SW24LE
Japan: ? ARIB STD-T66: 204-650001

Protocol

SW2.4LE

Frequency

2.4 - 2.4835 GHz

Transmission power

max. 10 dBm (10mW)

Data rate

1000 kbps

Wireless range

max. 45 m indoors

Channel spacing

2000 kHz

Modulation type

GFSK, adaptive frequency hopping of 40 channels
