RF magnet antenna R-SMA plug-in connector straight 2 m
Article no.: 1470773
Standard version
contact us
Product features
RF magnet antenna with straight R-SMA plug-in connector without ferrite core
Suitable for SW915 and SW917
Cable length 2 m
Integrated magnetic base
Suitable for indoor use only
Technical data
General technical data
- Frequency range
- 824 - 960 MHz, 1.7 GHz / 1.9 GHz
- Impedance
- 50 Ω
- Gain
- 2 dBi
- Polarization
- linear
- Connection
- cable RG174
- Cable length
- 2 m
- Connector
- R-SMA (male)
- Ambient temperature
- –40 °C … +85 °C
- Note
- Magnetic antennae must be mounted on a metal plate of min. 250 x 250 mm size.
- Weight
- 43 g
Dimensional drawing
Further drawings
Arrangement of receiver and switch antenna
A = Optimum mounting
B = Possible mounting
C = Unsuitable mounting
