Product features
Thermoplastic enclosure
sWave® wireless technology
No power supply, no wiring and pipe laying required
Easy programming of receiver
Output signal can be individually configured at the receiver
Actuator: Key switch RSSA with safety cylinder lock (locks against turning)
Standard version always has same key number
Switching position RSSA 14 (versions with other switching positions available on request)
Notes
Available on request in different versions
Technical data
General technical data
Applied standards
EN 60947-5-1, EN 61000-6-2, EN 61000-6-3, EN 301 489-1, EN 301 489-3, EN 300 220-1, EN 300 220-2
Enclosure
thermoplastic
Degree of protection
IP65 (IEC/EN 60529)
Voltage source
electrodynamic energy generator
Ambient temperature
–20 °C … +65 °C
Operation cycles
max. 12000 telegrams with repetitions/h
Mechanical life
> 1 million operations
Actuating time
min. 80 ms
Note
no status signal available
Wireless approvals
Brazil: ANATEL 04580-18-06718
Wireless technology
Protocol
sWave®
Frequency
917 MHz (Brazil)
Transmission power
< 25 mW
Data rate
66 kbps
Channel bandwidth
550 kHz
Wireless range
max. 450 m outdoors, max. 40 m indoors
