Product features
Thermoplastic enclosure
sWave® wireless technology
No wiring and pipe laying required
Plug-in connector M8
Power supply by Lithium battery
Easy programming of receiver
Output signal can be individually configured at the receiver
LBT - Listen before Talk software (necessary in conjunction with potential interference)
Notes
Connection of external switching contact (potentialfree contact) with gold contacts possible.
Technical data
General technical data
Applied standards
EN IEC 60947-5-1, EN IEC 61000-6-2, EN IEC 61000-6-3, EN 61000-4-2, EN 301 489-1, EN 301 489-3, EN 300 220-1, EN 300 220-2
Enclosure
thermoplastic, glass-fibre reinforced, self-extinguishing UL 94 V-0
Tightening torque
enclosure mounting screws: 0.5 … 0.6 Nm
Degree of protection
IP67 (IEC/EN 60529)
Connection
Plug-in connector M8 x 1, 3-pole
Mechanical life
> 1 million operations
Telegram rate
max. 12000 telegrams with repetitions/h
Actuating time
min. 80 ms
Ambient temperature
–20 °C … +65 °C
Note
no status signal available
transmission of battery voltage and switching condition
Wireless approvals
Europe: RED 2014/53/EU
Weight
50 g
Wireless technology
Protocol
sWave®
Frequency
868.3 MHz (Europe)
Transmission power
< 25 mW
Data rate
66 kbps
Channel bandwidth
350 kHz
Wireless range
max. 450 m outdoors, max. 40 m indoors
Modulation type
2-FSK
Voltage supply
Voltage source
lithium battery CR 2032 (replaceable)
System
Lithium-MnO2
Nominal voltage
3 V
Nominal capacity
0.23 Ah
Battery life
> 800 000 operations
