Safety sensor
RC Si M30 1Ö/1S - LED - 5m
Article no.: on request
This product is only available on request, please contact our sales team. contact usProduct features
Metal enclosure
Long life
Reed contacts, coded
Actuation from front
Switching distance up to 10 mm
With pre-wired cable
Version with LED lamp
Notes
2 mounting nuts are included in delivery
The actuator is not included in the delivery of the switches
Technical data
General technical data
Applied standards
EN ISO 13849-1, EN ISO 14119, EN IEC 60947-5-2, EN 60947-5-3*
Enclosure
brass, nickeled
Sensor type
type 4 interlocking device
Coding level
low coding
Tightening torque
mounting nut: max. 75 Nm
Degree of protection
IP67 (IEC/EN 60529)
Switching system
reed contacts
Switching elements
1 NC/1 NO contact
Connection
pre-wired cable H03VV-F
Cable cross-section
4 x 0.5 mm²
Cable length
5 m
Switching voltage
max. 30 VDC
Rated operating current/voltage Ie/Ue
max. 20 mA / 24 VDC
Utilisation category
DC-12
Voltage drop at Ie
max. 3 V
Short-circuit current Ik
max. 30 mA for 50 ms
Degree of pollution
3
Safety class
II
Rated switching distance sn
10 mm
Assured switching distance »ON« sao
8 mm
Assured switching distance »OFF« sar
30 mm
Repeatability
< 0.5 mm
Hysteresis
≤ 14 mm
Ambient temperature
–20 °C … +70 °C
Storage and shipping temperature
–30 °C … +85 °C
Mechanical life
> 10 million operations
Safety-relevant data
EN ISO 13849-1
Performance Level PL e
Category
4
B10d (10 % load)
20 million
TM
max. 20 years
MTTFd
> 100 years
DC/DCavg
> 99 %
hop
8 h/day
dop
220 days/year
tzyklus
20 s
Note
The safety-related data are only valid in combination with a safety module, e.g. SRM 21 RT2 (mat. no. 1179203).
