Safety sensor
RC Si 56 1Ö/1S - 2m - IP69 Extreme
Article no.: 1188983Old article no.: 25609201
contact usProduct features
Version with higher degree of protection IP69: suitable for cleaning with 80 °C hot water at 100 bar pressure at a distance of 100 mm from different directions
Thermoplastic enclosure
Long life
Reed contacts, coded
Actuation from front
Switching distance up to 6 mm
With pre-wired cable
Attention: Please state required international approvals with your order!
Notes
The actuator is not included in the delivery of the switches
Technical data
General technical data
Applied standards
EN 60947-5-1, EN 60947-5-3, EN ISO 13849-1, EN ISO 14119
Enclosure
thermoplastic, glass-fibre reinforced, shockproof, self-extinguishing UL 94 V-0
Sensor type
type 4 interlocking device
Coding level
low coding
Degree of protection
IP66, IP67, IP69 (IEC/EN 60529) / IP69K (ISO 20653)
Switching system
reed contacts
Switching elements
1 NC/1 NO contact
Connection
pre-wired cable 4 x AWG 24
Cable cross-section
4 x 0.22 mm²
Cable length
2 m
Switching voltage
max. 30 VDC
Rated operating current/voltage Ie/Ue
max. 157 mA / 24 VDC
Utilisation category
DC-12
Voltage drop at Ie
max. 3.15 V
Short-circuit current Ik
max. 750 mA for 50 ms
Rated switching distance sn
6 mm
Assured switching distance »ON« sao
4 mm
Assured switching distance »OFF« sar
> 23 mm
Repeatability
< 0.5 mm
Hysteresis
min. 23 mm
Degree of pollution
3
Safety class
II
Ambient temperature
–20 °C … +85 °C
Mechanical life
> 1 million operations
Approvals
d
Weight
100 g
Safety-relevant data
EN ISO 13849-1
Performance Level PL e
Category
4
B10d (10 % load)
2 million
TM
max. 20 years
MTTFd
> 100 years
DC/DCavg
> 99 %
Note
The safety-related data are only valid in combination with a safety module, e.g. SRM 21 RT2 (mat. no. 1179203).
Downloads
Variants / Options
The following variants / options are available on request:
Maritime certification to DNV <
