Magnetic sensor
RC M20 1W-1m
Article no.: on request
This product is only available on request, please contact our sales team. contact usProduct features
Metal enclosure
Long life
1 Reed contact
Actuation from front
Switching distance up to 30 mm depending on the actuating magnet
With pre-wired cable
Notes
2 mounting nuts are included in delivery
The actuator is not included in the delivery of the switches
Technical data
General technical data
Applied standards
EN IEC 60947-5-2
Enclosure
brass, nickeled
Degree of protection
IP67 (IEC/EN 60529)
Switching system
reed contacts
Switching elements
1 change-over contact
Connection
pre-wired cable H05VV-F
Cable cross-section
3 x 0.75 mm²
Cable length
1 m
Switching voltage
max. 250 VAC/DC
Switching current
max. 1.5 A
Switching capacity
max. 50 W/VA
Ambient temperature
–10 °C … +80 °C
Mechanical life
109 operations
Repeatability
± 0.02 mm
Vibration resistance
1S: 50 … 100 g, 1W: 10 … 50 g
Weight
350 g
Downloads
Variants / Options
The following variants / options are available on request:
Stainless steel enclosure
Maritime certification to DNV <
