Product features
Metal enclosure
Long life
1 Reed contact
Actuation from front and from side
Switching distance up to 29 mm depending on the actuating magnet
With pre-wired cable
Notes
1 mounting nut is included in delivery
The actuator is not included in the delivery of the switches
Technical data
General technical data
Applied standards
EN IEC 60947-5-2
Enclosure
aluminium
Degree of protection
IP67 (IEC/EN 60529)
Switching system
reed contacts
Switching elements
1 change-over contact
Connection
pre-wired cable PVC
Cable cross-section
3 x 0.5 mm²
Cable length
5 m
Switching voltage
max. 250 VAC/DC
Switching current
max. 0.5 A
Switching capacity
max. 15 W
Ambient temperature
–10 °C … +80 °C
Mechanical life
109 operations
Repeatability
± 0.02 mm
Vibration resistance
35 g (10-1000 Hz)
Shock resistance
50 g (11 ms, ½ sin)
Weight
280 g
