Ex cable protection adapter M20x1.5 external / NW12 with strain relief
Article no.: 1183846
Product features
For indoor and outdoor application
With integrated strain relief
Corrosion-resistant
Prevents electrostatic charging
With external thread M20x1,5
Compatible with cable protection conduit NM 12 (1183844)
Technical data
General technical data
- Applied standards
- EN IEC 60079-0, EN IEC 60079-7, EN 60079-31
- Adapter
- PA12, dissipative, with nickel-plated brass thread, black
- Degree of protection
- IP68 (IEC/EN 60529)
- Clamping range
- cable Ø 6.5-9.5 mm
- Impact energy
- max. 7 J
- Ambient temperature
- –5 °C … +85 °C
- Ex marking
- Ex eb IIC Gb,
Ex tb IIIC Db
- Approvals
- SEV 15 ATEX 0121X
IECEx SEV 15.0009X
Dimensional drawing
