Standard version
Belt alignment switch
ES 98 SR-11
Article no.: 1248307Old article no.: 9100310001
contact usProduct features
Metal enclosure
2 contacts
Design to EN 50041
Wiring compartment
Adjustable-length stainless steel rod lever with nylon roller
Belt alignment lever adjustable in 13° steps using a self-locking mechanism
For light- and medium-heavy applications
Technical data
General technical data
Applied standards
EN ISO 13849-1, EN 60947-5-1
Enclosure
aluminium die-cast, powder-coated
Degree of protection
IP67 (IEC/EN 60529)
B10d (10 % load)
2 million
TM
max. 20 years
Contact material
silver
Switching system
slow action
Switching elements
1 NC/1 NO contact, type Zb
Connection
screw connection terminals
Cable cross-section
max. 2.5 mm² (incl. conductor ferrules)
Cable entry
1 x M20 x 1.5
Rated impulse withstand voltage Uimp
4 kV
Rated insulation voltage Ui
250 V
Conventional thermal current Ithe
6 A
Rated operating current/voltage Ie/Ue
6 A/250 VAC; 0.25 A/230 VDC
Utilisation category
AC-15; DC-13
Short-circuit protection
6 A gG/gN fuse
Mechanical life
> 1 million operations
Operation cycles
max. 1800/h
Ambient temperature
–20 °C … +60 °C
Approvals
da
Weight
400 g
