ES 97 Z 11

Applied standards

EN 60947-5-1

Enclosure

thermoplastic, glass-fibre reinforced, shockproof, self-extinguishing UL 94 V-0, weathering resistant, UV stabilised

Degree of protection

IP66/IP67 (IEC/EN 60529)

Switching system

slow action

Switching elements

1 NC/1 NO contact, type Zb

Connection

screw connection terminals

Cable cross-section

0.34 ... 2.5 mm² (incl. conductor ferrules)

Cable entry

1 x M20 x 1.5

Rated impulse withstand voltage U_imp

6 kV

Rated insulation voltage U_i

500 V

Conventional thermal current I_the

10 A

Utilisation category

AC-15; DC-13

Rated operating current/voltage I_e/U_e

AC: 24 V-10 A/120 V-6 A/400 V-4 A
DC: 24 V-6A/125 V-0.55 A/250 V-0.4 A
Minimum electrical load: 5 V/10 mA

Short-circuit protection

10 A gG/gL fuse

Conditional short-circuit current

1000 A

Operation cycles

max. 1800/h

Mechanical life

1 million operations

Ambient temperature

–30 °C … +70 °C

Actuating force

approx. 25 N

Enclosure material resistant to:
oil and petrol, alcohol, animal fats and oils, vegetable fats and oils, silicone oils, surfactants, detergents, water vapour, salt water, organic acids (citric acid, benzoic acid)

Enclosure material not resistant to:
mineral acids (concentrated hydrochloric acid, battery acid, sulphuric acid, nitric acid)
