Contact diagram
Switching diagram

Pull-wire switch

ES 61 WZ 1Ö/1S -40°C IP67 Extreme

Article no.: 1188177Old article no.: 61042907

contact us

Product features

  • Cold-resistant down to -40 °C

  • High degree of protection IP67

  • Metal enclosure

  • Wall mounting

  • Slow action

  • 2 contacts

  • Pull-wire function

  • Attention: Please state required international approvals with your order!

Technical data

Applied standards

EN 60947-5-1

Enclosure

aluminium die-cast, powder-coated

Cover

steel, powder-coated

Sealing

silicone

Degree of protection

IP67 (IEC/EN 60529)

Contact material

silver

Switching elements

1 NC/1 NO contact, type Zb

Switching system

slow action

Connection

screw connection terminals

Cable cross-section

max. 2.5 mm² (incl. conductor ferrules)

Cable entry

3 x M20 x 1.5

Rated impulse withstand voltage Uimp

6 kV

Rated insulation voltage Ui

400 V

Conventional thermal current Ithe

16 A

Utilisation category

AC-15

Rated operating current/voltage Ie/Ue

16 A/400 VAC

Short-circuit protection

16 A gG/gN fuse

Ambient temperature

–40 °C … +80 °C

Mechanical life

> 1 million operations

Operation cycles

max. 3600/h

Actuating force

max. 50 N

Approvals

a

Weight

370 g

Downloads

Mounting and wiring instructions – ES/EM 41 Z / ES 41 WH/90° / ES 51 Z / ES/EM 61 Z / ES 95 Z / ZS 70 Z / ZS 71 Z

German, English, French, Italian, Portuguese

PDF2 MB 04.02.2025
