Product features
Metal enclosure
Snap action, change-over contact with single break
Suitable for in-line mounting
With pre-wired cable
Actuator: Rod lever DD
Wear-resistant plastic tip
Lever can be repositioned in 10° steps clockwise or counter-clockwise
Notes
Actuator can be repositioned by 180° on request
Technical data
General technical data
Applied standards
EN 60947-5-1
Enclosure
aluminium die-cast, powder-coated
Degree of protection
IP67 (IEC/EN 60529)
Contact material
silver
Switching elements
1 change-over contact with single break, type C
Switching system
snap action
Connection
pre-wired cable H05VV-F
Cable cross-section
4 x 0.75 mm²
Cable length
2 m
Rated impulse withstand voltage Uimp
4 kV
Rated insulation voltage Ui
250 V
Conventional thermal current Ithe
5 A
Utilisation category
AC-15; DC-13
Rated operating current/voltage Ie/Ue
5 A/250 VAC; 0.16 A/230 VDC
Short-circuit protection
5 A gG/gN fuse
Mechanical life
> 1 million operations
Operation cycles
max. 1800/h
Ambient temperature
–20 °C … +75 °C
Approvals
a
Downloads
Variants / Options
The following variants / options are available on request:
Gold-plated contacts
Cable entry on side
Plug-in connector M12 x 1, 5-pole
Plug-in connector M12 x 1, 4-pole
Mounting thread M16 x 1.5
